Specifications

• Gauge: #7
• Length: 9/16"
• Head Type: Reduced Modified Truss Head
• Bit Tip: Phillips Bit Tip
• Thread Type: Fine Thread
• Coating: Black Phosphate
• Point Type: Vector Point

Benefits

• Grabber’s Pro-Fit™ #2 Phillips recess is a precision recess designed for better bit engagement resulting in less wobble or strip-out.
• The reduced modified truss head design works in conventional plastic strip collation
• Grabber sharp point reduced modified truss head screws begin with the best available materials and conform to strict manufacturing requirements in thread forming. Extra sharp threads mean screws will drive faster and will hold better.
• The super-sharp Vector™ point starts and drives up to 40% faster than most other fine thread metal framing screws.

Installation Guide

• Use a standard screwgun with a depth sensitive nose piece. Suggested screwgun specification for optimal performance – Size #7, up to 4,000 RPM.
• The head is fully seated when the bearing surface of the head is flush with the work surface.
• The fastener must penetrate beyond the metal three full thread pitches.
• Overdriving may result in failure of the fastener or failure of the gypsum board.
